Lifetime seam warranty
Therma-Seal seams are covered 100% for the life of the liner, the strongest seam guarantee in the industry.
Replacement Liners · Modesto, CA
Doughboy Replacement Pool Liners, Measured Right The First Time
Whether your liner is faded, leaking, or stretched out after a decade of Central Valley summers, Gordo's Pool City helps Modesto, Turlock, and Stockton pool owners pick the exact replacement liner, by shape, wall height, attachment style, and thickness, and stand behind it with the same Doughboy authorized dealer that's been here since 1956.
Why Doughboy Liners
The Only Above-Ground Liner Made By The Pool Manufacturer
Doughboy is the only above-ground pool brand that produces its own liner vinyl. No clay fillers, no reprocessed material, and Therma-Seal seam technology that's covered 100% for the life of the liner, a guarantee no other manufacturer offers.
100% virgin vinyl
No clay fillers and no reprocessed vinyl. Resists cracking in freezing conditions and holds color through Central Valley sun.
True mil thickness
Doughboy measures liners in true mil, the industry standard. Beware competitors that quote "gauge" to make thinner vinyl look thicker.
Warranty-safe replacement
Installing any non-Doughboy liner voids your pool warranty. We make sure the right liner ships with the right receiver, every time.
2026 Liner Lineup
E-Z Clip, Overlap, Expandable, And In-Ground, Compared
Match the attachment style and thickness to your existing pool. Not sure what you have? Snap a photo of the top rail and bring a measurement, we'll identify it on the spot.
| Series | Type | Thickness | Warranty | Styles available |
|---|---|---|---|---|
| E-Z Clip 4000 | E-Z Clip | 20 mil | 25-Year | Blue Grotto (new), Terrazzo, Triton, Evening Star |
| Overlap 4000 UD | Overlap standard | 20 mil | 20-Year | Solid Blue |
| Overlap 4000 Exp | Overlap expandable | 20 mil | 25-Year | Sunset Cove, Misty Falls, Blue Bayou, Solid Blue |
| Overlap 5000 Exp | Overlap expandable | 25 mil | 30-Year | Blue Topaz (new), Solid Blue |
| Inground Premium | In-ground | 20 mil | 25-Year | Terrazzo, Evening Star |
20 and 25 mil expandable liners stretch to allow a 7-foot deep swim area. In-ground Premium liners ship via Branded MFG.
Gauge vs. Mil
The Most Confusing Number In The Above-Ground Liner Aisle, Explained
"Gauge" is a marketing term. "Mil" is a real measurement. Before you spend money on a replacement liner, here's exactly what the numbers mean, and why a true mil-rated Doughboy liner is almost always thicker than the gauge number on a competitor's box.
Mil is a real measurement
One mil equals 1/1000 of an inch. A 20 mil liner is exactly 0.020" of vinyl, the same on every box, from every manufacturer. When Doughboy says 20 mil or 25 mil, you can put a caliper on it and prove it.
Gauge is a marketing term
"Gauge" has no fixed conversion to a physical thickness. Manufacturers use it to make thinner vinyl look thicker on the shelf, and in many cases, "30 gauge" is only "approximately 15 mil." It also lets them use thinner vinyl on the floor than on the wall.
Industry "Gauge" vs. actual thickness in mil
Approximate conversions reported by liner manufacturers and the broader plastics industry. Numbers vary by brand, always ask for the actual mil thickness in writing.
| Marketed gauge | Wall (actual mil) | Floor (actual mil) | What it really means |
|---|---|---|---|
| 20 Gauge | ~11–13 mil | ~12 mil | Marketed as the "standard" but is the thinnest vinyl on the market. |
| 25 Gauge | ~14–15 mil | ~13 mil | Often sold as an "upgrade", still thinner than a true 20 mil Doughboy liner. |
| 30 Gauge | ~15–17 mil | ~15 mil | Frequently described as "approximately 15 mil" in the fine print. |
| 35 Gauge | ~18–19 mil | — | Thickness and floor weight vary by manufacturer. |
| 40 Gauge | ~20–22 mil | — | Top of most gauge charts, still no guaranteed floor thickness. |
Source: published manufacturer charts and the U.S. plastics-film convention that 100 gauge = 1 mil. Pool-liner "gauge" is not the same scale, which is exactly the confusion this chart exposes.
What Doughboy actually delivers
Doughboy is the only above-ground pool brand that manufactures its own vinyl, in true mil thickness, with the same gauge on the wall and the floor, backed by the Therma-Seal lifetime seam warranty.
| Series | True thickness | Warranty |
|---|---|---|
| Overlap 4000 / E-Z Clip 4000 | True 20 mil wall and floor | 20–25 year limited warranty |
| Overlap 5000 Expandable | True 25 mil wall and floor | 30 year limited warranty |
| Therma-Seal seams | Heat-welded virgin vinyl | Covered 100% for the life of the liner |
Why people buy their liner at Gordo's
- We quote in mil, not gauge. You'll always know the real wall and floor thickness before you pay.
- Authorized Doughboy dealer since 1956. Liners are sourced from the factory with the matching receivers, hardware, and warranty paperwork.
- We protect your pool warranty. A non-Doughboy liner voids the pool warranty, we make sure that does not happen by accident.
- Central Valley measurements done right. We confirm shape, wall height, attachment style, and bottom type so the liner fits the first time.
- Local support after the sale. A real phone number, a real store at 6167 Yosemite Blvd, and trusted installer referrals.
Pro tip from our liner desk: if a competitor will not give you the actual mil thickness of the wall and the floor in writing, assume the floor is thinner than the wall. Then compare that number, not the gauge, to a true 20 mil or 25 mil Doughboy liner.
2026 Pattern Library
Every Doughboy Liner Pattern, In One Place
Browse the full pattern lineup by liner type. Bring your pool measurements to the Modesto showroom and we'll match the right pattern, gauge, and attachment style to your existing pool.
Expandable Liners
For deep-end hopper installations
Expandable liners stretch at the bottom to accommodate a dug-out swim area up to about 7 feet deep. Available in standard 20mil and premium 25mil gauges.
20mil Print Patterns
Standard-gauge expandable liners. Designer prints sized for every Doughboy pool.
25mil Premium Patterns
Premium thicker-gauge expandable for enhanced durability. Blue Topaz available now; additional 25mil prints available on request.
Uniform Depth (UD) Liners
Flat-bottom, consistent depth across the entire pool
UD liners maintain a level floor wall-to-wall, ideal for lap swimming, exercise, and families that want safe, predictable footing throughout the pool. All Uniform Depth liners are 20mil.
20mil Patterns
EZ-Clip Liners
Snap-in fit. No bead track. Clean top edge.
EZ-Clip liners snap directly onto the top of the pool wall for a secure, wrinkle-free fit. Every EZ-Clip order ships with the matching EZ-Clip Receiver.
52" / 54" Wall Patterns
48" Wall Patterns
EZ-Clip liners sized for 48" wall height pools are available, contact us for current pattern availability and the right sizing for your pool.
Note: pattern colors on screen are a guide only, actual liner color and texture can vary slightly between print runs. Stop by the showroom to see large physical swatches before you commit.
How To Measure
A 5-Step Liner Measurement Guide For Above-Ground Pools
Get these five pieces of information before you order. The right answer the first time saves you weeks of waiting on a re-ship, and saves the install crew a return trip.
- 1
Confirm the shape
Round or oval? Oval liners also need the support buttress style and end-cap style, bring a photo if you're unsure.
- 2
Measure the diameter or length × width
Take the measurement at the top of the wall, in feet. For ovals, measure the longest dimension and the shortest dimension.
- 3
Measure the wall height
48", 52", or 54". Measure from the bottom of the rail to the bottom track inside the pool, don't measure the outside.
- 4
Identify the attachment
Overlap drapes over the wall, E-Z Clip snaps into a receiver bead at the top, J-Hook hangs over a coping strip. Look at the top edge of your current liner.
- 5
Check the bottom
Flat bottom or expandable (hopper) bottom? A 20 or 25 mil expandable liner can stretch to a 7-foot deep swim area.
Not sure what you're looking at?
Take photos of the top rail, the inside of the pool wall, and the existing liner pattern, then bring them to 6167 Yosemite Blvd. We'll identify the series and order the correct replacement, including the E-Z Clip Receiver if your liner needs one.
Liner replacement process
In-store identification, ordering, and installer referral. Most replacements turn around in 2–3 weeks once measurements are confirmed.
Installation referrals
Trusted Central Valley liner crews who follow Doughboy specs and protect your factory warranty.
Why buy it here
Local expertise, warranty-safe parts, the right receivers in the box, and a phone number you can call when something needs attention.
Made in America for over 75 years
American-Made Liners From An American-Made Pool Brand
Doughboy is the only above-ground pool manufacturer that produces its own liner vinyl, in the United States, with 100% virgin material and Therma-Seal seams covered for the life of the liner. No clay fillers, no reprocessed vinyl, no overseas substitutes. American-made quality, sold and supported by Gordo's Pool City since 1956.
Liner Customers
Trusted with their liner, and everything after.
Verified Google reviews from Central Valley pool owners who rely on Gordo's for liners and long-term support.
4.2 on Google · 82+ reviewsPaul Smith
Modesto, CA · Jan 2023
Google Review“I have known John for quite some time now. He is the “pool guy.” He and his staff know their stuff about pools and pool care, as well as spas. As long as he is in business, he will have my business.”
Charles Morales
Modesto, CA · Jan 2024
Google Review“They are right there explaining step by step how to complete the work.”
Rebecca Lux
14-year customer · Jun 2019
Google Review“Gordo's has everything!!! Plus their clerks have the pool knowledge I needed. If they didn't know they'd turn you over to the owner or someone with more experience. It's the only place I'll go and feel at ease about what I'm buying. 14-year customer, I give you a 5 star ☆☆☆☆☆.”
Liner Quote
Help us measure the right liner for your pool.
Share what we need to identify the correct fit. We'll confirm the right liner, and the right receiver or coping, before you order.
Frequently asked questions
The Questions Modesto Pool Owners Ask Us Most About Liners
Honest, specific answers from a Doughboy dealer that has been replacing liners in the Central Valley for nearly 70 years.
